Storag
e
locatio
n
Items Range: Description
[D+3]
Number of occurrences of synchronous
abnormality
[D+4]
Number of occurrences of transmission
answer NACK
[D+5]
Number of occurrences of three
consecutive transmission answers
NACK
[D+6]
Number of occurrences of transmission
answer WACK
[D+7]
Number of occurrences of three
consecutive transmission answers
WACK
[D+8]
Number of occurrences of non-
response
[D+9]
Number of occurrences of three
consecutive non-response
[D+10]
Number of occurrences of receive
command code error
[D+11]
Number of occurrences of received
data CRC error
[D+12]
Number of absences of received data
end code
[D+13]
Number of occurrences of received
data format error
[D+14]
Number of occurrences of received
data NOT support error
■
Acquired data (PLC link refresh operation monitoring information): When [S] = 3
Storage
locatio
n
Items Range: Description
[D]
RING counter for the
number of receptions
U0 to U65535
The number of receptions is stored. When the value
exceeds 65535, it returns to 0.
[D+1]
Current receive
interval (x 1 ms)
-
The reception interval is stored.[D+2]
Minimum receive
interval (x 1 ms)
-
[D+3]
Maximum receive
interval (x 1 ms)
-
[D+4]
RING counter for the
number of
transmissions
U0 to U65535
The number of transmissions is stored. When the value
exceeds 65535, it returns to 0.
[D+5]
Current send interval
(x 1 ms)
-
The send interval is stored.
16.3 PMGET (Acquiring MEWNET-W Parameters)
16-12 WUME-FP7CPUPGR-12
