Panasonic FP7 Series Command Reference Manual

[S] value Type of acquired data
Number of stored
data
Storage location
0 PLC link communication state 6 word [D] to [D+5]
1 Network participation state 5 word [D] to [D+4]
2 W2 link error system counter type error area 18 word [D] to [D+17]
3 W2 link error system error register area 10 word [D] to [D+9]
■
Acquired data (PLC link communication state): When [S] = 0
Storage
location
Items Range: Description
[D] to [D+1]
PLC link state monitor flag
station number 1 to 32
H0 to
HFFFFFFFF
Bit 0 to bit 31: Unit number 1 to unit number
32
OFF: Stopped
ON: PLC link communicating normally
[D+2] to [D
+3]
PLC link operation mode flag
station number 1 to 32
Bit 0 to bit 31: Unit number 1 to unit number
32
OFF: PROG mode
ON: RUN mode
[D+4] to [D
+5]
PLC link operation state flag
station number 1 to 32
Bit 0 to bit 31: Unit number 1 to unit number
32
OFF: No error
ON: Error occurs in PLC for which
transmission assurance is ON.
(Note 1) Even when (3) has been set for the PLC link operation state flag in the configuration "W2 link unit
setting" of the tool software, the data of 6 words is read by the PMGET instruction.
■
Acquired data (network participation state): When [S] = 1
Storage
location
Items Range: Description
[D]
Number of units added
to the link
U0 to U64
The number of units added to the link is stored. The value is
0 when the existing unit in the network is only one or a
station number is being changed.
[D+1]
Link participation unit
flag
Unit nos. 1 to 16
H0 to
HFFFF
Bit 0 to bit 15: Unit number 1 to unit number 16
OFF: Not exist
ON: Participating
[D+2]
Link participation unit
flag
Unit nos. 17 to 32
Bit 0 to bit 15: Unit number 17 to unit number 32
OFF: Not exist
ON: Participating
[D+3]
Link participation unit
flag
Unit nos. 33 to 48
Bit 0 to bit 15: Unit number 33 to unit number 48
OFF: Not exist
ON: Participating
[D+4]
Link participation unit
flag
Unit nos. 49 to 64
Bit 0 to bit 15: Unit number 49 to unit number 64
OFF: Not exist
ON: Participating
16.4 PMGET (Acquiring MEWNET-W2 Parameters)
WUME-FP7CPUPGR-12 16-15
