[S1][S2]
Storage
location
Name
Number
of words
Forma
t
Description
[D+33] - [D
+40]
Default gateway (IPv6) 8
Hexad
ecimal
Default gateway
[D+41] - [D
+43]
Master unit MAC address 3
Hexad
ecimal
Master unit MAC address
Total number of words 44 -
[S1]: "IPv6"
[S2]:
"CONNECT"
[D] - [D+7]
Master unit IP address 1
(IPv6)
8
Hexad
ecimal
Master unit IPv6 address (Manual
setting)
[D+8]- [D
+15]
Master unit IP address 2
(IPv6)
8
Hexad
ecimal
Home IPv6 address (Link local)
(Note 2)
[D+16] - [D
+23]
Master unit IP address 3
(IPv6)
8
Hexad
ecimal
Home IPv6 address (Router)
(Note
3)
[D+24] - [D
+31]
Master unit IP address 4
(IPv6)
8
Hexad
ecimal
Home IPv6 address (DHCP)
(Note
3)
[D+32] Subnet prefix length 1
Decim
al
Subnet prefix length
[D+33] - [D
+40]
Default gateway (IPv6) 8
Hexad
ecimal
Default gateway
[D+41]
Destination IP address
type
1
Decim
al
1:IPv6
[D+42] - [D
+49]
Destination IP address 8
Hexad
ecimal
Destination IP address (for IPv6)
(Note 4)
Total number of words 50
[S1]: "Ipv6"
[S2]:
"CONNECT
1"
or
"CONNECT
2"
[D] - [D+7]
Master unit IP address 1
(IPv6)
8
Hexad
ecimal
Master unit IPv6 address (Manual
setting)
[D+8]- [D
+15]
Master unit IP address 2
(IPv6)
8
Hexad
ecimal
Home IPv6 address (Link local)
(Note 2)
[D+16]- [D
+23]
Master unit IP address 3
(IPv6)
8
Hexad
ecimal
Home IPv6 address (Router)
(Note
3)
[D+24]- [D
+31]
Master unit IP address 4
(IPv6)
8
Hexad
ecimal
Home IPv6 address (DHCP)
(Note
3)
[D+32] Subnet prefix length 1
Decim
al
Subnet prefix length
[D+33]- [D
+40]
Default gateway (IPv6) 8
Hexad
ecimal
Default gateway
[D+41] Master unit port number 1
Decim
al
The master unit port number in
use
[D+42]
Destination IP address
type
1
Decim
al
1:IPv6
[D+43]- [D
+50]
Destination IP address 8
Hexad
ecimal
Destination IP address (for IPv6)
(Note 4)
[D+51] Destination port number 1
Decim
al
Partner unit port number
(Note 4)
Total number of words 52 -
17.2 ETSTAT (Acquiring Ethernet Unit Information: IP/MAC/Destination)
