[S1][S2]
Storage
location
Name
Number
of words
Forma
t
Description
or
"CONNECT
2"
[D+4]- [D+7] Subnet mask (IPv4) 4
Decim
al
Subnet mask
[D+8]- [D
+11]
Default gateway (IPv4) 4
Decim
al
Default gateway
[D+12] Master unit port number 1
Decim
al
The master unit port number in
use
[D+13]
Destination IP address
type
1
Decim
al
0:IPv4
[D+14]- [D
+17]
Destination IP address 4
Decim
al
Destination IP address (for IPv4)
(Note 2)
[D+18] Destination port number 1
Decim
al
Partner unit port number
(Note 2)
Total number of words 19 -
(Note 1) For IPv4, a decimal number is stored in each area of the storage.
Example) When the master unit IP address is 192.168.1.5, the IP address is stored as follows:
[D]=U192, [D+1]=U168, [D+2]=U1, [D+3]=U5
(Note 2) The destination varies depending on the setting of the communication method (TCP/UDP) as shown in
the following table.
Communication
method
Setting of [S2]
CONNECT, CONNECT1 CONNECT2
TCP client
Partner unit (server) that is set as the
destination
Partner unit (server) to which
the connection is established
No connection is established:
0
TCP server (specific
partner unit)
Partner unit (client) that is allowed to be
connected
Partner unit (client) whose
connection is established
No connection is established:
0
TCP server (any
partner unit)
Partner unit (client) that is connected
most recently
A partner unit (client) has never been
connected: 0
UDP Partner unit that is set as the destination (for master communication)
[S1][S2]
Storage
location
Name
Number
of words
Forma
t
Description
[S1]: "IPv6"
[S2]: "MAC"
[D] - [D+7]
Master unit IP address 1
(IPv6)
8
Hexad
ecimal
Master unit IPv6 address (Manual
setting)
[D+8]- [D
+15]
Master unit IP address 2
(IPv6)
8
Hexad
ecimal
Home IPv6 address (Link local)
(Note 2)
[D+16] - [D
+23]
Master unit IP address 3
(IPv6)
8
Hexad
ecimal
Home IPv6 address (Router)
(Note
3)
[D+24] - [D
+31]
Master unit IP address 4
(IPv6)
8
Hexad
ecimal
Home IPv6 address (DHCP)
(Note
3)
[D+32] Subnet prefix length 1
Decim
al
Subnet prefix length
17.2 ETSTAT (Acquiring Ethernet Unit Information: IP/MAC/Destination)
WUME-FP7CPUPGR-12 17-7
