Page #898 background image
Value Description
DT13
Example) AA-BB-CC-DD-EE-FF
HCCDD
DT14 HEEFF
Example 2) When specifying IPv4 address and the destination IP address of a
specified connection
The results are stored in the 17-word area that starts with [D].
[S1]... "IPv4" [S2]... "CONNECT" [D]...DT0
Value Description
DT0 H00C0 (U192)
The master unit IPv4 address is stored.
Example) 192.168.5.30
DT1 H00A8 (U168)
DT2 H0005 (U5)
DT3 H001E (U30)
DT4 H00FF (U255)
The subnet mask is stored.
Example) 255.255.255.0
DT5 H00FF (U255)
DT6 H00FF (U255)
DT7 H0000 (U0)
DT8 H00C0 (U192)
Default gateway
Example) 192.168.5.1
DT9 H00A8 (U168)
DT10 H0005 (U5)
DT11 H0001 (U1)
DT12 H0000 This value indicates the type of the IP address. For IPv4, the value is "0".
DT13 H00C0 (U192)
The destination IPv4 address is stored.
Example) 192.168.5.11
DT14 H00A8 (U168)
DT15 H0005 (U5)
DT16 H000B (U11)
Example 3) When specifying IPv6 address and the destination IP address of a
specified connection
The results are stored in the 50-word area that starts with [D].
[S1]... "IPv6" [S2]... "CONNECT" [D]...DT0
Value Description
DT0 HFE80
The master unit IPv6 address (manual setting) is stored.
Example) fe80:0011:2233:4455:6677:8899:aabb:ccdd
DT1 H0011
DT2 H2233
DT3 H4455
DT4 H6677
DT5 H8899
DT6 HAABB
DT7 HCCDD
17.2 ETSTAT (Acquiring Ethernet Unit Information: IP/MAC/Destination)
17-10 WUME-FP7CPUPGR-12
