an operand, set string data using the SSET instruction in advance. However, the ESSET
instruction cannot be used because the format is different.
● The number of characters should not exceed 256.
● Both upper and lower case characters can be used. "Abcd", "ABCD" and "abcd" are all
synonymous. However, the folder name and the file name that are included in a path name
are case-sensitive.
● This instruction is not available in interrupt programs.
■
Operand [S1] setting
● Specify the starting address of the device area that stores the string data that indicates a
transfer setting number, or a character constant.
Setting
item
Settings
Setting
range
S1
Transfer setting
number
Specify a transfer setting number. ID=: Transfer setting
number
0 to 15
(Note 1) Transfer setting numbers should be specified from number 0 in ascending order. An error occurs when
transfer setting numbers are not specified in ascending order. If transfer settings have been already
registered, this rule is not applied.
Setting example
Exam
ple 1
S1 “ID=1”
Settings Transfer setting number: 1
Exam
ple 2
S1 “ID=8”
Settings Transfer setting number: 8
■
Operand [S2] setting
● Specify the starting address of the device area that stores the operation setting parameter, or
a character constant.
Setting
item
Settings
S2
Specification of
FTP server
Specify FTP servers. (3 digits fixed)
SV0: Server 0, SV1: Server 1, SV2: Server 2, SV3: Server 3
Target and
operation of
transfer
Set the target for the transfer and operation.
Parameter string Target Transfer operation
PUTFILE File Send to servers (Overwrite method)
PUTFILE-OVW File Send to servers (Overwrite method)
PUTFILE-REN File Send to servers (Rename method)
GETFILE File Obtain from servers
PUTDATA Device Send to servers (Overwrite method)
PUTDATA-OVW Device Send to servers (Overwrite method)
PUTDATA-REN Device Send to servers (Rename method)
GETDATA Device Obtain from servers
17.12 FTPcSET (FTP Client Transfer Setting)
WUME-FP7CPUPGR-12 17-61
