Operand [S3] setting (UPDOWN operation for a device)
● Specify the starting address of the device area that stores the string data that indicates
source device settings, or a character constant.
● Downloaded data is stored immediately after uploaded data. The number of acquisitions (the
number of bytes) is stored in the first two words.
Setting
item
Settings Setting range
S3
Source device
setting
Specify the source device setting.
● Global devices
Specify device code + device number.
● Local devices
"PB" + PB number + "_" (underscore) + device code +
device number
<Devices that can be specified>
Global devices Local devices
WX WX
WY WY
WR WR
WL WL
DT DT
LD LD
Number of
transferred data
(number of
bytes)
Specify the number of transferred data (number of bytes). (1 to
7 digits)
* The number of bytes that can be simultaneously transferred
is 1 MB for all 16 IDs.
1 to 1048576
(1MB)
Maximum
number of
acquisitions
(number of
bytes)
Specify the maximum number of acquisitions (number of
bytes). (1 to 7 digits)
* Data can be obtained up to the maximum number of
acquisitions.
* The number of bytes that can be simultaneously acquired is 1
MB for all 16 IDs.
1 to 1048576
(1MB)
(Note 1) Input each source device setting parameter separated by a comma ",".
(Note 2) Specify the operation setting parameters in the order of the above table.
Setting example
Exam
ple 1
S3 "WX16,32.32"
Settings
Device setting, Device division: Global, Device code: WX, Device number: 16, Number of bytes:
32 bytes,
Number of acquisitions: 32 bytes
Exam
ple 2
S3 "DT123456,250,250"
Settings
Device setting, Device division: Global, Device code: DT, Device number: 123456, Number of
bytes: 250 bytes,
Number of acquisitions: 250 bytes
17.17 HTTPcSET (HTTP Client Transfer Setting)
17-92 WUME-FP7CPUPGR-12
