88A-35
WIRING HARNESS
Passenger compartment rear wiring: Removal - Refitting
88A
-the upper C-pillar trims,
-the luggage compartment side trims.
a Partially remove the headlining (see Roof trim as-
sembly: Exploded view) (71A, Body internal trim).
4 - Passenger compartment rear wiring section in
the rear doors
a Remove the rear side door trim (see Rear side door
trim: Removal - Refitting) (72A, Side opening ele-
ment trim).
5 - Passenger compartment rear wiring section in
the tailgate
a Remove the tailgate trim (see ) (73A, Non-side
opening elements trim).
6 - Passenger compartment rear wiring section in
the wheel arches
a Remove:
-the rear wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres)
- the ABS sensor cover.
II - REMOVAL OPERATION
1 - Passenger compartment rear wiring section on
the floor
a Disconnect all the connectors.
a Unclip the wiring section where indicated.
a Remove the earth terminals where indicated.
a Remove the wiring section.
144401
