Renault Duster 2007 - Rear Screen: Removal - Refitting

54A-8
WINDOWS
Rear screen: Removal - Refitting
54A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove:
-the tailgate trim (see Tailgate trim: Removal - Re-
fitting) (73A, Non-side opening elements trim),
-the rear screen wiper arm (see Rear screen wiper
arm: Removal - Refitting) (85A, Wiping - Wash-
ing),
-the rear screen wiper motor (see Rear screen wip-
er motor: Removal - Refitting) (85A, Wiping -
Washing),
-the high level brake light (see 3rd brake light: Re-
moval - Refitting) (81A, Rear lighting).
a Disconnect the heated rear screen wiring harness.
II - REMOVAL OPERATION
a Protect the edges of the rear screen using masking
tape.
a Cut the cement bead (see Technical Note 0560A).
a Remove the rear screen window (this operation re-
quires two people).
REFITTING
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: Rear screen adjust-
ing shim
a Refit the rear screen wiper motor (see Rear screen
wiper motor: Removal - Refitting) (85A, Wiping -
Washing) to act as a guide for positioning the rear
screen.
a For preparation and bonding (see Technical Note
0560A).
II - REFITTING OPERATION FOR PART
CONCERNED
a Bond the rear screen (two people are required for
this operation).
a Equal out the clearances and shut lines.
a Remove the tabs from the stops once the adhesive
has dried.
III - FINAL OPERATION
a Connect the heated rear screen wiring harness con-
nectors.
a Refit:
- the high level brake light (see 3rd brake light: Re-
moval - Refitting) (81A, Rear lighting),
- the rear screen wiper arm (see Rear screen wiper
arm: Removal - Refitting) (85A, Wiping - Wash-
ing),
- the rear screen wiper blade (see Rear screen wip-
er blade: Removal - Refitting) (85A, Wiping -
Washing),
- the tailgate trim (see Tailgate trim: Removal - Re-
fitting) (73A, Non-side opening elements trim).
125437
