Renault Duster 2007 - Air Mixing Cable: Removal - Refitting

61A-15
HEATING
Air mixing cable: Removal - Refitting
AIR CONDITIONING or STANDARD HEATING RECIRCULATION
61A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Lock the airbag computer (see Fault finding - Re-
placement of components) (88C, Airbags and pre-
tensioners).
a Disconnect the battery (see Battery: Removal - Re-
fitting) (80A, Battery).
a Turn the heating and air conditioning mixing control
to the hottest position.
a Remove:
-the driver's front airbag (see Driver's frontal air-
bag: Removal - Refitting) (88C, Airbags and pre-
tensioners),
-the steering wheel (see Steering wheel: Removal
- Refitting) (36A, Steering assembly),
-the steering column switch assembly (see Steer-
ing column switch assembly: Removal - Refit-
ting) (84A, Control - Signals),
-the instrument panel (see Instrument panel: Re-
moval - Refitting) (83A, Instrument panel),
-the storage compartment,
-the radio (see Radio: Removal - Refitting) (86A,
Radio),
-the dashboard (see Dashboard: Removal - Refit-
ting) (57A, Interior equipment).
a Disconnect the climate control panel connector .
II - REMOVAL OPERATION
a Remove:
- the sheath stop by moving the tab (3) to one side,
- the air mixing cable (4) from the control panel.
a Unclip the distribution unit cable sleeve stop (5) .
a Extract the end of the air mixing cable (6) .
H79
125537
145422
