54A-3
WINDOWS
Front side door sliding window: Removal - Refitting
54A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove the front side door trim (see Front side
door trim: Removal - Refitting) (72A, Side opening
elements trim).
a Remove the interior weatherstrip.
a Lower the window.
a Remove the exterior weatherstrip.
II - REMOVAL OPERATION
a Remove the bolts (1) .
a Remove the window.
REFITTING
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: front side opening
element sliding window bolt
107946
145088
107945
107951
