Renault Duster 2007 - Rocker Cover: Removal - Refitting

11A-42
TOP AND FRONT OF ENGINE
Rocker cover: Removal - Refitting
K4M
11A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Disconnect the battery (see Battery: Removal - Re-
fitting) (80A, Battery).
a Remove:
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-2) ,
-the air resonator (see 12A, Fuel mixture, Air res-
onator: Removal - Refitting, page 12A-2) ,
-the timing belt (see 11A, Top and front of engine,
Timing belt: Removal - Refitting, page 11A-17) ,
-the air filter unit (see 12A, Fuel mixture, Air filter
unit: Removal - Refitting, page 12A-6) ,
-the throttle valve (see 12A, Fuel mixture, Throttle
valve: Removal - Refitting, page 12A-11) ,
-the inlet distributor (see 12A, Fuel mixture, Inlet
distributor: Removal - Refitting, page 12A-12) ,
-the timing end camshaft seals (see 11A, Top and
front of engine, Camshaft seal, timing end: Re-
moval - Refitting, page 11A-56) ,
-the ignition coils (see 17A, Ignition, Coils: Re-
moval - Refitting, page 17A-1) ,
-the oil decanter (see 11A, Top and front of en-
gine, Oil decanter: Removal - Refitting, page
11A-68) ,
-the flywheel end lifting eye on the rocker cover.
Tightening torquesm
rocker cover bolts 22,
23, 20 and 13
8 N.m
rocker cover bolts 1 to
12, 14 to 19, 21 to 24
15 N.m
rocker cover bolts 22,
23, 20 and 13
15 N.m
flywheel end lifting eye
bolts on the rocker cover
11 N.m
