Renault Duster 2007 - Front Electric Window Switch: Removal - Refitting

87D-2
ELECTRIC WINDOWS - SUNROOF
Front electric window switch: Removal - Refitting
ELECTRIC FRONT WINDOW or FRONT ONE-TOUCH ELECTRIC WINDOW
87D
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove the radio (see 86A, Radio, Radio: Remov-
al - Refitting, page 86A-3) .
a Unclip the central trim assembly, starting at the bot-
tom.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Disconnect the front left window winder switch con-
nector (1) or the front right window winder switch
connector (2) .
a Unclip the front window winder switch by pressing
the clips.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Clip on the front window winder switch.
a Connect the connector.
II - FINAL OPERATION
a Clip on the central trim assembly, starting at the top.
a Refit the radio (see 86A, Radio, Radio: Removal -
Refitting, page 86A-3) .
125726
125727
