81A-2
REAR LIGHTING
Rear wing light: Removal - Refitting
81A
Location and specifications (tightening torques, parts
always to be replaced, etc.) (see 81A, Rear lighting,
Rear light assembly: Exploded view, page 81A-1)
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Switch off the ignition.
Rear light on the wing (right-hand side)
a Remove
-the jack cover,
-the jack.
II - REMOVAL OPERATION
a Remove (see 81A, Rear lighting, Rear light as-
sembly: Exploded view, page 81A-1) :
-the nuts of the rear light on the wing,
-the rear light on the wing.
a Disconnect the connector from the rear light on the
wing (see 81A, Rear lighting, Rear light assem-
bly: Exploded view, page 81A-1) .
When replacing the rear light on the wing
a Remove the bulbs from the rear light on the wing
(see 81A, Rear lighting, Rear light assembly: Ex-
ploded view, page 81A-1) .
REFITTING
a Proceed in the reverse order to removal.
