80D-9
V1
MR-453-X79-80D000$060.mif
80D
UCH
Vdiag No.: 09
SUB-FUNCTION: LIGHTING CONTROL
NOTES
Only carry out this conformity check after a complete check using the diagnostic tool.
The values shown in this conformity check are given as a guide.
Test conditions: Engine stopped, ignition on.
Function
Parameter or status
Checked or action
Display
and notes
Fault finding
Lighting
control
ET324 Side lights request
"PRESENT"
or
"ABSENT"
In the event of an
inconsistency, apply the
interpretation of status ET324.
ET485
Hazard warning
lights signal
"PRESENT"
or
"ABSENT"
In the event of an
inconsistency, apply the
interpretation of status ET485.
ET084
Right-hand
indicator request
"PRESENT"
or
"ABSENT"
In the event of an
inconsistency, apply the
interpretation of status ET084.
ET083
Left-hand indicator
request
"PRESENT"
or
"ABSENT"
In the event of an
inconsistency, apply the
interpretation of status ET083.
UCH_V09_CCONF
LIGHTING
Fault finding – Conformity check
