Renault Duster 2007 - Passenger Compartment Fan Assembly Control Unit: Removal - Refitting

61A-28
HEATING
Passenger compartment fan assembly control unit: Removal - Refitting
61A
REMOVAL
REMOVAL OPERATION
a Remove the lower trim of the dashboard (depending
on the equipment level).
a Disconnect the connector (1) from the passenger
compartment fan assembly control unit.
a Remove:
-the bolt (2) from the passenger compartment fan
assembly control unit,
-the passenger compartment fan assembly control
unit.
REFITTING
a Proceed in the reverse order to removal.
Note:
It is not necessary to remove the dashboard to
remove the passenger compartment fan assembly
control unit.
108102
