11A-68
TOP AND FRONT OF ENGINE
Oil decanter: Removal - Refitting
K4M
11A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove:
-the air resonator (see 12A, Fuel mixture, Air res-
onator: Removal - Refitting, page 12A-2) ,
- the air filter unit (see 12A, Fuel mixture, Air filter
unit: Removal - Refitting, page 12A-6) ,
-the throttle valve (see 12A, Fuel mixture, Throttle
valve: Removal - Refitting, page 12A-11) ,
- the inlet distributor (see 12A, Fuel mixture, Inlet
distributor: Removal - Refitting, page 12A-12) ,
- the ignition coils (see 17A, Ignition, Coils: Re-
moval - Refitting, page 17A-1) .
II - REMOVAL OPERATION
a Remove:
-the oil decanter bolts,
-the oil decanter.
Tightening torquesm
new oil separator bolts 15 N.m
14497-4
