Renault Duster 2007 - Engine - Gearbox Assembly: Removal - Refitting

10A-54
ENGINE AND CYLINDER BLOCK ASSEMBLY
Engine - gearbox assembly: Removal - Refitting
K4M
10A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Drain the refrigerant circuit using the tool refrigerant
charging station (see Refrigerant circuit: Drain-
ing - Filling) (62A, Air conditioning).
a Remove:
- the air inlet sleeve,
- the battery (see Battery: Removal - Refitting)
(80A, Battery),
- the air resonator (see 12A, Fuel mixture, Air res-
onator: Removal - Refitting, page 12A-2) ,
- the air filter unit (see 12A, Fuel mixture, Air filter
unit: Removal - Refitting, page 12A-6) ,
- the injector rail protector,
- the battery tray,
- the injection computer (see 17B, Petrol injection,
Petrol injection computer: Removal - Refitting,
page 17B-7) .
Special tooling required
Mot. 1448 Remote operation pliers for
hose clips.
Mot. 1390 Support for removal - refitting
of engine - gearbox assembly
Equipment required
refrigerant charging station
Tightening torquesm
nut on the rubber pad
support of the left-hand
suspended engine
mounting
62 N.m
exhaust flange bolts 21 N.m
front axle subframe tie-
rod upper bolts
21 N.m
anti-roll bar tie rod
upper bolts
37 N.m
earth strap bolt on the
gearbox
21 N.m
power-assisted steering
low pressure pipe bolt
on the front axle sub-
frame
21 N.m
power-assisted steering
pipe bolts on the gear-
box support
21 N.m
power-assisted steering
pipe bolts on the gear-
box
21 N.m
power-assisted steering
pipe bolt on the cylinder
block
21 N.m
IMPORTANT
Wear cut-resistant gloves during the operation.
IMPORTANT
To prevent the vehicle from falling, lash it to the
vehicle lift using a strap.
AIR CONDITIONING
