19A
-
19
COOLING
Thermostat: Removal - Refitting
K9K
19A
a
The thermostat is integral with the coolant outlet
unit. The coolant outlet unit must be replaced to re-
place it (see
19A
,
Cooling
,
Water chamber: Re-
moval - Refitting
, page
19A-22
) .
319
321
