37A-24
MECHANICAL COMPONENT CONTROLS
Accelerator pedal cable: Removal - Refitting
K4M, and 4X2 TRANSMISSION
37A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove the brake fluid reservoir (see 37A, Me-
chanical component controls, Master cylinder:
Removal - Refitting, page 37A-2) .
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Disconnect the accelerator pedal cable at (1) .
a Extract the clip (2) from the accelerator cable on the
pedal.
a Push the accelerator cable sheath stop into the en-
gine compartment.
RIGHT-HAND DRIVE
LEFT-HAND DRIVE
122818
RIGHT-HAND DRIVE
121585
