37A-9
MECHANICAL COMPONENT CONTROLS
Brake servo non-return valve: Removal - Refitting
LEFT-HAND DRIVE
37A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove the engine cover.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Disconnect the non-return valve at (1) on the brake
servo.
a Pull and turn the non-return valve to release it from
the rubber sealing washer.
a Disconnect the non-return valve at (3) on the vacu-
um pump.
K9K
108933
K9K
24753
