37A-8
MECHANICAL COMPONENT CONTROLS
Master cylinder - front left-hand calliper brake pipe: Removal - Refitting
LEFT-HAND DRIVE, and WITHOUT ANTI-LOCK BRAKING SYSTEM
37A
REFITTING
I - REFITTING STAGE FOR THE PART IN
QUESTION
a Refit the brake pipe between the master cylinder
and the front left-hand brake hose.
a Refit the brake pipe on the retaining bracket.
a Clip the brake pipe into its clip.
a Screw the brake pipe union on the front left-hand
brake hose.
a Screw the brake pipe union on the master cylinder.
a Torque tighten:
-the brake pipe union on the master cylinder (14
N.m),
-the brake pipe union on the brake hose (14
N.m).
II - FINAL OPERATION
a Refit:
-the front engine cover (if fitted to the vehicle),
-the front left-hand wheel (see 35A, Wheels and ty-
res, Wheel: Removal - Refitting, page 35A-1) .
a Bleed the brake circuit (see 30A, General informa-
tion, Braking circuit: Bleed, page 30A-4) .
