62A-23
AIR CONDITIONING
Pressure sensor: Removal - Refitting
AIR CONDITIONING
62A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Disconnect the battery (see Battery: Removal - Re-
fitting) (MR 388, 80A, Battery).
a Remove:
-the engine cover,
-the air intake sleeve.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Disconnect the pressure sensor.
a Remove the pressure sensor (1) .
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Refit the pressure sensor.
a Torque tighten the pressure sensor (9 N.m).
a Connect the pressure sensor.
II - FINAL OPERATION.
a Refit:
- the air inlet sleeve,
- the engine cover.
a Connect the battery (see Battery: Removal - Refit-
ting) (MR 388, 80A, Battery).
Tightening torquesm
pressure sensor 9 N.m
24780
Note:
An automatic shut-off valve isolates the circuit
from the outside during removal; do not drain the
refrigerant from the circuit.
