82D-33
AFTER REPAIR
Carry out another fault finding check on the system.
Deal with any other faults.
Clear the stored faults.
V1
MR-453-X79-82D000$150.mif
82D
UCH
Vdiag No.: 09
AC004
OPENING ELEMENT LOCKING
NOTES
There must be no present or stored faults.
This command is for testing locking relay operation.
This command lasts for 2 seconds.
Special note:
Use the Wiring Diagrams Technical Note for DUSTER.
Check the condition and the connection of the UCH connector, component code 645 (see MR 451, Mechanical,
87B, Passenger compartment connection unit).
If the connector is faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the connector,
otherwise replace the wiring.
Check the condition and connection of the connectors of the following faulty lock(s): the rear right-hand door
electric lock, component code 138, the rear left-hand door electric lock, component code 139, the driver's door
electric lock, component code 140, the passenger door electric lock, component code 141, the boot lid electric lock,
component code 142.
If the connectors are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the connector, otherwise
replace the wiring.
Check the insulation, continuity and the absence of interference resistance on the following connections:
• 20C between components 138 and 645,
• 20C between components 139 and 645,
• 20C between components 140 and 645,
• 20C between components 141 and 645,
• 20C between components 142 and 645.
If the connection or connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault)
or Technical Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring,
otherwise replace it.
If the fault is still present, contact the Techline.
UCH_V09_ AC004
ACCESS – SAFETY
Fault finding – Interpretation of commands
