17A-1
IGNITION
Coils: Removal - Refitting
K4M
17A
REMOVAL
REMOVAL OPERATION
a Disconnect the connectors (1) from the ignition coils.
a Remove:
-the ignition coil bolts (2) ,
-the ignition coils.
REFITTING
I - REFITTING PREPARATION OPERATION
a Always replace the ignition coil bolts.
a If necessary, replace the ignition coil O-rings.
Tightening torquesm
ignition coil bolts 14 N.m
116655
