17A-2
IGNITION
Coils: Removal - Refitting
K4M
17A
a When refitting the ignition harness, it is essential to
apply a bead of FLUOSTAR 2L 2 mm in diameter
around the inner edge of the high-tension caps on
the side of the spark plugs and coil (see Vehicle:
Parts and consumables for the repair) (04B, Con-
sumables-Products).
II - REFITTING OPERATION
a Refit:
-the ignition coils,
-the new ignition coil bolts.
a Torque tighten the ignition coil bolts (14 N.m).
a Connect the ignition coil connectors.
106443
