Renault Duster 2007 - Master Cylinder - Front Left-Hand Calliper Brake Pipe: Removal - Refitting

37A-7
MECHANICAL COMPONENT CONTROLS
Master cylinder - front left-hand calliper brake pipe: Removal - Refitting
LEFT-HAND DRIVE, and WITHOUT ANTI-LOCK BRAKING SYSTEM
37A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Fit a pedal press to the brake pedal to limit outflow.
a Remove:
-the front left-hand wheel (see 35A, Wheels and ty-
res, Wheel: Removal - Refitting, page 35A-1) ,
-the front engine cover (if fitted to the vehicle).
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Unscrew the brake pipe union (1) from the brake
hose.
a Remove the brake pipe from the retaining bracket.
a Unclip the brake pipe from its clip (2) .
a Unscrew the brake pipe union (3) from the master
cylinder.
a Remove the brake pipe between the master cylinder
and the front left-hand brake hose.
Equipment required
pedal press
Tightening torquesm
brake pipe union on the
master cylinder
14 N.m
brake pipe union on the
brake hose
14 N.m
117816
118630
