71A-1
BODY INTERNAL TRIM
Interior body side trim assembly: Exploded view
H79
71A
(see ) (01D, Mechanical introduction)
145783
Mark Description Information
1 C-pillar upper trim (Car. 1363)
2 Rear parcel shelf side trim bolt
3 Rear parcel shelf side trim
4 Rear wheel arch trim (Car. 1363)
5 Rear wheel arch trim bolt
6 C-pillar trim (Car. 1363)
7 B-pillar upper trim (Car. 1363)
8 Rear side door seal
9 B-pillar lower trim (Car. 1363)
