Renault Duster 2007 - Front Side Door Lock: Removal - Refitting

51A-5
SIDE OPENING ELEMENT MECHANISMS
Front side door lock: Removal - Refitting
51A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove:
-the front side door trim (see Front side door trim:
Removal - Refitting) (72A, Side opening element
trim).
-the support of the front side door run channel (see
51A, Side opening element mechanisms, Front
side door slide mounting: Removal - Refitting,
page 51A-21) .
a Remove the bolts (1) from the impact padding with-
out removing it.
II - REMOVAL OPERATION
a Unclip the exterior opening control linkage (3) from
the clip (4) on the exterior door handle.
a Remove the front side door lock catch (5) .
a Disconnect the connector (6) from the lock motor.
24835
145250
145495
DOOR OPENING SYSTEM 02
145617
