Renault Duster 2007 - Rear Quarter Panel Window: Removal - Refitting

54A-7
WINDOWS
Rear quarter panel window: Removal - Refitting
54A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove (see Interior body side trim assembly:
Exploded view) :
-the C-pillar trim,
-the parcel shelf side trim,
-the C-pillar upper trim.
II - REMOVAL OPERATION
a Protect the edges of the quarter panel window using
masking tape.
a Cut the cement bead (see Technical Note 0560A).
a Remove the rear quarter panel window (this opera-
tion requires two people).
REFITTING
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: Windscreen adjust-
ing shim.
a Fit new shims and retaining stops.
a For preparation and bonding (see Technical Note
0560A).
II - REFITTING OPERATION
a Bond the rear quarter panel window (this operation
requires two people).
a Equal out the clearances and shut lines.
a Remove the tabs from the stops when the adhesive
has dried.
III - FINAL OPERATION
a Proceed in the reverse order to removal.
145582
