Renault Duster 2007 - Rear Side Seat Belt: Removal - Refitting

88C-22
AIR BAG AND PRETENSIONERS
Rear side seat belt: Removal - Refitting
88C
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove (see ) :
-the rear bench seat base,
-the rear side seat belt lower bolt,
-the single unit rear bench seatback.
a Remove the parcel shelf structure trim (see Interior
body side trim assembly: Exploded view) .
II - REMOVAL OPERATION
a Remove:
-the rear side seat belt inertia reel bolt (1) ,
-the rear side seat belt.
REFITTING
I - REFITTING PREPARATION OPERATION
a Coat the threads of the side seat belt bolts using
HIGH STRENGTH THREAD LOCK (see Vehicle:
Parts and consumables for the repair) (04B, Con-
sumables - Products).
II - REFITTING OPERATION
a Proceed in the reverse order to removal.
a Torque tighten the rear side seat belt bolts (21
N.m).
Tightening torquesm
rear side seat belt bolts 21 N.m
145578
