31A-30
FRONT AXLE COMPONENTS
Front hub carrier bearing: Removal - Refitting
31A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Remove the front wheel (see 35A, Wheels and ty-
res, Wheel: Removal - Refitting, page 35A-1) .
a Remove the front wheel speed sensor (see 38C,
Anti-lock braking system, Front wheel speed
sensor: Removal - Refitting, page 38C-7) .
a Remove:
-the front brake disc (see 31A, Front axle compo-
nents, Front brake disc: Removal - Refitting,
page 31A-15) ,
- the front driveshaft hub carrier (see 31A, Front
axle components, Front driveshaft hub carrier:
Removal - Refitting, page 31A-27) .
II - REMOVAL OPERATION
a Remove the elastic ring (1) from the front driveshaft
hub carrier.
a Remove the hub with a press, applying pressure
with a tube with an external diameter of 42 mm.
IMPORTANT
To avoid all risk of damage to the systems, apply
the safety and cleanliness instructions and opera-
tion recommendations before carrying out any
repair (see 31A, Front axle components, Front
axle components: Precautions for the repair,
page 31A-1) .
WARNING
In order not to damage the brake hose:
- do not tension the hose,
- do not twist the hose,
- check that there is no contact with the surrounding
components.
WARNING
In order to prevent irreversible damage to the front
hub bearing:
- Do not loosen or tighten the driveshaft nut when
the wheels are on the ground.
- Do not place the vehicle with its wheels on the
ground when the driveshaft has been loosened or
removed.
ANTI-LOCK BRAKING SYSTEM
101933
20786
