52A-2
NON-SIDE OPENING ELEMENT MECHANISMS
Exterior rear opening element assembly: Exploded view
52A
Mark Description Information
1 Bonnet Material: Steel
(see Bonnet: Removal - Refit-
ting) (48A, Non-side opening ele-
ments).
(see Steel bodywork compo-
nent: Preparation and paint
range) (Technical Note 0592A,
Paint application range for panels).
2 Front bumper Material: P/E
(see 55A, Exterior protection,
Front bumper: Removal - Refit-
ting, page 55A-8)
(see 55A, Exterior protection,
Front bumper assembly:
Exploded view, page 55A-1)
(see Polypropylene bodywork
component: Preparation and
paint range) (Technical Note
0592A, Paint application range for
plastic).
(see Plastic material bodywork
component: Repair) (50A, Gen-
eral information).
3 Bonnet hinge
4 Front wing Material: Steel
(see Front wing: Removal - Refit-
ting) (42A, Upper front structure).
(see Steel bodywork compo-
nent: Preparation and paint
range) (Technical Note 0592A,
Paint application range for panels).
5 Side pressure piece of front
bumper
6 Rivet of side pressure piece of front
bumper
7 Front section of sill panel extender (see 56A, Exterior equipment,
Exterior body side trim assem-
bly: Exploded view, page 56A-1)
8 Front wheel arch liner Material: P/E
9 Fog light (see Front fog light bulb:
Removal - Refitting) (80B Head-
lights).
