81A-1
REAR LIGHTING
Rear light assembly: Exploded view
81A
144000
1 Brake light and side light bulb
(see 81A, Rear lighting, Rear light bulb:
Removal - Refitting, page 81A-3)
2 Direction indicator bulb
3 Fog or reversing light bulb
4 Rear light (see 81A, Rear lighting, Rear wing light:
Removal - Refitting, page 81A-2)
