Renault Duster 2007 - Front Fog Light Bulb: Removal - Refitting

80B-6
HEADLIGHTS
Front fog light bulb: Removal - Refitting
80B
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Remove:
-the clips (1) ,
-the front wheel arch side liner.
a Remove the bolts (2) .
a Move aside the front wheel arch liner.
II - REMOVAL OPERATION
a Disconnect the front fog light connector (3) .
a Remove the front fog light bulb anticlockwise.
REFITTING
a
a Proceed in the reverse order to removal.
145207
145206
144539
144837
Note:
When replacing a bulb, only use approved bulbs.
