Renault Duster 2007 - Front Axle System: Tightening Torque

30A-16
GENERAL INFORMATION
Front axle system: Tightening torque
30A
145734
No. Description Tightening torque (N.m
(2) Lower arm bolt 180
(3) Subframe tie-rod lower bolt 21
(6) Anti-roll bar bearing bolt 21
(7) Calliper support bolt 107
Front sub-frame bolt 110
Steering box bolt on the subframe 180
(10) Front subframe bracket bolt 44
No. Description Tightening torque (N.m)
(1) « Spring - shock absorber » assembly nut on the body 44
(4) Track rod end nut 37
(8) Subframe tie-rod upper bolt on the side member 21
(9) Shock absorber bolt on the hub carrier 105
