30A-17
GENERAL INFORMATION
Front axle system: Tightening torque
30A
109719
No. Description Tightening torque (N.m)
(12) Shock absorber nut for spring cup 62
(14) Lower arm ball joint bolt or nut 62
(15) Driveshaft nut 280
(16) Wheel bolts 105
(18) Axial ball joint mounting on the steering rack 34
(19) Disc bolt 14
No. Description Tightening torque (N.m)
(12) Anti-roll bar tie-rod nuts 21
(17) Wheel alignment lock nut 53
