Renault Duster 2007 - Front Wheel Arch Liner: Removal - Refitting

55A-10
EXTERIOR PROTECTION
Front wheel arch liner: Removal - Refitting
55A
Location and specifications (tightening torques, parts
always to be replaced, etc.) (see 55A, Exterior pro-
tection, Exterior body front trim assembly: Explod-
ed view, page 55A-5) .
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Remove the front wheel on the side concerned (see
Wheel: Removal - Refitting) (35A, Wheels and ty-
res).
II - REMOVAL OPERATION
a Remove (see 55A, Exterior protection, Exterior
body front trim assembly: Exploded view, page
55A-5) :
-the front wheel arch liner bolts,
-the front wheel arch liner clips,
-the front wheel arch liner.
REFITTING
a Proceed in the reverse order to removal.
