Renault Duster 2007 - Rear Light Bulb: Removal - Refitting

81A-3
REAR LIGHTING
Rear light bulb: Removal - Refitting
81A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Switch off the ignition.
a Remove the rear light on the wing (see 81A, Rear
lighting, Rear light assembly: Exploded view,
page 81A-1) .
II - REMOVAL OPERATION
a Unclip the bulb holder by pressing on the clips (1) .
1 - Brake light and side light bulb
a Remove the brake light and side light bulb (see 81A,
Rear lighting, Rear light assembly: Exploded
view, page 81A-1) .
2 - Direction indicator bulb
a Remove the direction indicator bulb (see 81A, Rear
lighting, Rear light assembly: Exploded view,
page 81A-1) .
3 - Fog or reversing light bulb
a Remove the fog or reversing light bulb (see 81A,
Rear lighting, Rear light assembly: Exploded
view, page 81A-1) .
REFITTING
a Proceed in the reverse order to removal.
145583
