Renault Duster 2007 - Crankshaft Accessories Pulley: Removal - Refitting

11A-10
TOP AND FRONT OF ENGINE
Crankshaft accessories pulley: Removal - Refitting
K9K
11A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Remove:
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
-the front right-hand wheel arch side liner,
-the front right-hand wheel arch partially (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection),
-the plastic shield underneath the diesel filter,
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-2) .
II - REMOVAL OPERATION
a Remove:
-the crankshaft accessories pulley bolt (2) , locking
the flywheel using a large screwdriver (1) ,
- the crankshaft accessories pulley (3) .
Special tooling required
Mot. 1489 TDC locating pin.
Tightening torquesm
accessories pulley bolt 120 N.m + 95˚
±±
±±
15˚
TDC pin plug 25 N.m
IMPORTANT
Wear cut-resistant gloves during the operation.
WARNING
Do not run the engine without the accessories belt
to avoid damaging the crankshaft accessories pul-
ley.
135413
109938
