80D-2
V1
MR-453-X79-80D000$010.mif
80D
UCH
Vdiag No.: 09
1. SCOPE OF THIS DOCUMENT
This document presents the fault finding method applicable to all computers with the following specifications:
2. PREREQUISITES FOR FAULT FINDING
Documentation type
Fault finding procedures (this document):
– Assisted fault finding (integrated into the diagnostic tool), Dialogys.
Wiring Diagrams:
–Visu-Schéma.
Type of diagnostic tools
– CLIP
Special tooling required
If the information obtained by the fault finding tool requires the electrical continuity to be checked, connect
bornier Elé. 1622 or universal bornier Elé. 1681.
Vehicle(s): DUSTER
Function concerned: LIGHTING
Name of computer:UCH
Vdiag No.: 09
Special tooling required:
Diagnostic tool
Multimeter
Elé. 1622 Bornier
Elé. 1681 Universal bornier
WARNING:
–All tests with bornier Elé. 1622 or Elé. 1681 must be conducted with the battery disconnected.
– The bornier is only designed to be used with a multimeter. Never power the test points with 12 V.
UCH_V09_PRELI
LIGHTING
Fault finding – Introduction
