56A-2
EXTERIOR EQUIPMENT
Door mirror: Removal - Refitting
56A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove the front side door trim (see Front side
door trim: Removal - Refitting) (72A, Side opening
elements trim).
II - REMOVAL OPERATION
a Disconnect the connector (1) (depending on equip-
ment level).
a Remove the bolts (2) .
a Remove the door mirror.
REFITTING
a Proceed in the reverse order to removal.
107944
