Renault Duster 2007 - Steering Column Adjustment Handle: Removal - Refitting

36A-11
STEERING ASSEMBLY
Steering column adjustment handle: Removal - Refitting
36A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Disconnect the battery (see ) (80A, Battery).
a Remove:
-the bolts on the steering wheel lower cover,
-the half covers under the steering wheel (see In-
strument panel: Removal - Refitting) (83A, In-
strument panel),
-the immobiliser ring.
a Disconnect the various connectors.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Remove:
-the bolt (1) of the adjustment handle,
-the adjustment handle.
a
a Remove:
- the nut (2) of the adjustment handle shaft,
- the needle bearing,
- the « adjustment handle shaft - locking
mechanism » assembly.
133254
133255
Note:
Note the position of the locking mechanism
before removal.
