Renault Duster 2007 - Fault Finding - Interpretation of Faults

82D-19
V1
MR-453-X79-82D000$080.mif
82D
UCH
Vdiag No.: 09
DF180
PRESENT
OR
STORED
DECODER -> RING CONNECTION
CC.0: Short circuit to earth
CC.1: Short circuit to + 12 V
NOTES
Special note:
Use the Wiring Diagrams Technical Note for DUSTER.
CC.0
Check the connection and condition of the transponder ring connector, component
code 957.
If the connector is faulty and if there is a repair procedure (see Technical Note 6015A
(Renault) or Technical Note 9804A (Dacia), Electrical wiring repair, Wiring:
Precautions for repair), repair the connector, otherwise replace the wiring.
Check the connection and condition of the UCH connector, component code 645.
If the connector is faulty and if there is a repair procedure (see Technical Note 6015A
(Renault) or Technical Note 9804A (Dacia), Electrical wiring repair, Wiring:
Precautions for repair), repair the connector, otherwise replace the wiring.
Check the continuity and insulation against earth of the following connections:
– 80X between components 645 and 957.
If the connection or connections are faulty and if there is a repair procedure
(see Technical Note 6015A (Renault) or Technical Note 9804A (Dacia),
Electrical wiring repair, Wiring: Precautions for repair), repair the wiring,
otherwise replace it.
If the fault is still present, contact the Techline.
UCH_V09_DF180
ACCESS – SAFETY
Fault finding – Interpretation of faults
AFTER REPAIR
Follow the instructions.
Deal with any other faults.
Clear the stored faults.
