12A-1
FUEL MIXTURE
Air inlet: Description
K4M
12A
Diagram of the air inlet circuit
102071
(1) Air inlet trunking
(2) Air resonator
(3) Air filter unit
(4) Air filter
(5) Throttle valve
(6) Inlet manifold
(7) Injector holder shim
(8) Air inlet
