Renault Duster 2007 - Driveshafts; Front Left-Hand Driveshaft: Removal - Refitting

29A-1
DRIVESHAFTS
Front left-hand driveshaft: Removal - Refitting
JR5
29A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Remove:
-the engine undertray bolts,
-the engine undertray,
-the front left-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres).
a Drain the manual gearbox (see 21A, Manual gear-
box, Manual gearbox oils: Draining - Filling, page
21A-1) .
II - REMOVAL OPERATION
a Unclip:
- the wiring of the front left-hand wheel speed sensor
at (2) ,
- the brake hose of the front left-hand wheel at (3) .
a Remove:
- the hub nut (4) , using the,
- the track rod end nut (5) .
a Remove the left-hand track rod end using the tool (6)
.
Special tooling required
Emb. 880 Pin extractor tool.
Tav. 1813 Extraction claw for clip
secured type driveshafts
Tightening torquesm
shock absorber base
bolts
105 N.m
hub nut 280 N.m
track rod end nut 37 N.m
WARNING
In order to prevent irreversible damage to the front
hub bearing:
- Do not loosen or tighten the driveshaft nut when
the wheels are on the ground.
- Do not place the vehicle with its wheels on the
ground when the driveshaft has been loosened or
removed.
134508
24807
