51A-6
SIDE OPENING ELEMENT MECHANISMS
Front side door lock: Removal - Refitting
51A
a Remove the bolts (7) from the front side door lock.
a Unclip the interior opening control linkage at (8) .
a Remove the front side door lock and the interior
opening control linkage.
a Remove:
-the locking motor bolt (9) .
- the locking motor (10) .
REFITTING
a Proceed in the reverse order to removal.
a Refit the front side door impact padding (see Front
side door impact padding: Removal - Refitting)
(59A, Safety accessories).
a Carry out a function test.
145425
DOOR OPENING SYSTEM 02
108311
