16A-18
STARTING - CHARGING
Alternator pulley: Removal - Refitting
K9K
16A
a Fit:
-the splined socket (4) of thein the free wheel pulley
(5) ,
-the end piece and holder assembly (6) of theon the
alternator shaft.
a Immobilise the splined socket (4) .
a Torque tighten the alternator pulley nut (80 N.m).
a Turn the pulley by hand to check that the rotor turns
easily.
a Clip on the alternator pulley protector (if equipped).
II - FINAL OPERATION
a Refit:
-the alternator (see 16A, Starting - Charging, Al-
ternator: Removal - Refitting, page 16A-1) ,
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-2) .
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
114623
