11A-3
TOP AND FRONT OF ENGINE
Accessories belt: Removal - Refitting
K9K, and STANDARD HEATING RECIRCULATION
11A
REFITTING
I - REFITTING PREPARATION OPERATION
a
a Use a brush to remove any deposits from the crank-
shaft accessories pulley V-grooves.
a parts always to be replaced: Accessories belt
a parts always to be replaced: Accessories belt
tensioning roller
a parts always to be replaced: Accessories ten-
sioning roller bolt
II - REFITTING OPERATION FOR PART
CONCERNED
a Refit a new accessories belt tensioning roller.
Auto tensioner
a Torque tighten the new accessories belt tension-
ing roller bolt (40 N.m).
a Refit a new accessories belt.
a Rotate the crankshaft clockwise through two revolu-
tions (timing end).
III - FINAL OPERATION
a Refit:
-the front right-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection),
-the front wheel arch side liner,
-the plastic shield underneath the diesel filter,
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres).
WARNING
Only use brushes with plastic or non-corrosive
metal (brass) bristles.
