80D-24
AFTER REPAIR Carry out a road test, followed by a check with the diagnostic tool.
V1
MR-453-X79-80D000$100.mif
LIGHTING
Fault finding – Interpretation of commands
80D
UCH
Vdiag No.: 09
AC023
RIGHT-HAND INDICATOR
NOTES
This command is used to activate the right-hand indicator.
There must be no present or stored faults.
Switch on the ignition.
Special note:
Use the Wiring Diagrams Technical Note for DUSTER.
Check the condition of the right-hand indicator light bulb. Replace the bulb if necessary (see MR 451 Mechanical,
80B, Headlights, Side indicator: Removal - Refitting).
Check the connection and condition of the connector of the UCH, component code 645, the rear right-hand light,
component code 172, the right-hand headlight, component code 226, and the right-hand repeater, component
code 267.
If the connectors are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the connector, otherwise
replace the wiring.
Check for earth on the following connections:
• MA of component 226,
• MA of component 267,
• MF of component 172.
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
UCH_V09_AC023
